單路PFC
特點:
-通用交流輸入/全范圍
-小型化設計，體積緊湊，安裝方便
-高可靠性：采用高可靠性的優質電解電容
-寬工作范圍：-25℃至70℃
-保護功能：過載/過壓/過溫保護
-高效率，長壽命
-100%滿負載老化測試
-低紋波噪聲、低待機功耗、高效率
-滿足5000m海拔應用
-符合IEC/EN/UL/BSEN62368、EN60335、EN61558、EN62477、GB4943等認證標準
| 產品 | 系列標題 | 功率 | 輸入電壓 (VAC) |
輸入電壓 (VDC) |
輸出電壓 | 尺寸 | 安規認證 | 規格書 | 樣品申請 |
|---|---|---|---|---|---|---|---|---|---|
 |
BEF-100SX-50F▼ ▲ | 100W | 90V~264V | 2.8V-5V | 120×50×19mm |  |
 |
 |
|
 |
BEP-100SX-50F▼ ▲ | 100W | 176V~264V | 2.8V~5V | 120×50×19mm | |
|
|
|
|
BEF-200SX-50SF▼ ▲ | 200W | 90V~264V | 2.8V~5V | 137×50×19mm | |
|
|
|
|
BEP-200SX-50SF▼ ▲ | 200W | 176V~264V | 2.8V~5V | 137×50×19mm | |
|
|
|
|
BEF-200SX -50F▼ ▲ | 200W | 90V~264V | 2.8V~5V | 150×50×19mm | |
|
|
|
|
BEP-200SX-50F▼ ▲ | 200W | 176V~264V | 2.8V~5V | 150×50×19mm | |
|
|
|
|
BEF-200SX-60F▼ ▲ | 200W | 90V~264V | 2.8V~5V | 160×60×10mm | |
|
|
|
|
BEF-200SX-50LF▼ ▲ | 200W | 90V~264V | 2.8V~5V | 160×50×19mm | |
|
|
|
|
BEP-200SX-50LF▼ ▲ | 200W | 176V~264V | 2.8V~5V | 160x50x19mm | |
|
|
|
|
BEF-200SX-55M▼ ▲ | 200W | 90V~264V | 2.8V~5V | 165×55×23mm | |
|
|
|
|
BEP-200SX-55M▼ ▲ | 200W | 176V~264V | 2.8V~5V | 165×55×23mm | |
|
|
|
|
BEF-200SX-60M▼ ▲ | 200W | 90V~264V | 2.8V~5V | 208×60×26mm | |
|
|
|
|
BEP-200SX-60M▼ ▲ | 200W | 176V~264V | 2.8V~5V | 208×60×26mm | |
|
|
|
|
BEF-200SX-60M▼ ▲ | 200W | 90V~264V | 2.8V~5V | 208×60×30mm | |
|
|
|
|
BEP-200SX-60M▼ ▲ | 200W | 176V~264V | 2.8V~5V | 208×60×30mm | |
|
|
|
|
BEF-250SX-55M▼ ▲ | 250W | 90V~264V | 2.8V~5V | 165×55×23mm | |
|
|
|
|
BEP-250SX-55M▼ ▲ | 250W | 176V~264V | 2.8V~5V | 165×55×23mm | |
|
|
|
 |
BEF-300SX-55SM▼ ▲ | 300W | 90V~264V | 2.8V~5V | 165×55×23mm | |
|
|
|
|
BEP-300SX-55SM▼ ▲ | 300W | 176V~264V | 2.8V~5V | 165×55×23mm | |
|
|
|
|
BEF-300SX-55M▼ ▲ | 300W | 90V~264V | 2.8V~5V | 180×55×26mm | |
|
|
|
|
BEF-300SX-60M▼ ▲ | 300W | 90V~264V | 2.8V~5V | 208×60×26mm | |
|
|
|
|
BEP-300SX-60M▼ ▲ | 300W | 176V~264V | 2.8V~5V | 208×60×26mm | |
|
|
|
 |
BEF-400SX-68M▼ ▲ | 400W | 90V~264V | 2.8V~5V | 180×68×26mm | |
|
|
|
|
BEP-400SX-68M▼ ▲ | 400W | 176V~264V | 2.8V~5V | 180×68×26mm | |
|
|
|
|
BEF-400SX-60M▼ ▲ | 400W | 90V~264V | 2.8V~5V | 208×60×26mm | |
|
|
|
|
BEP-400SX-60M▼ ▲ | 400W | 176V~264V | 2.8V~5V | 208×60×26mm | |
|
|
|
|
BEF-400SX-32M▼ ▲ | 400W | 90V~264V | 2.8V~5V | 220×32×28mm | |
|
|
|
|
BEP-400SX-32M▼ ▲ | 400W | 176V~264V | 2.8V~5V | 220×32×28mm | |
|
|
|
|
BEF-400SX-38M▼ ▲ | 400W | 90V~264V | 2.8V~5V | 227×38×26mm | |
|
|
|
|
BEP-400SX-38M▼ ▲ | 400W | 176V~264V | 2.8V~5V | 220×38×26mm | |
|
|
|
|
BEF-400SX-46M▼ ▲ | 400W | 90V~264V | 2.8V~5V | 220×46×26mm | |
|
|
|
|
BEP-400SX-46M▼ ▲ | 400W | 176V~264V | 2.8V~5V | 220×46×26mm | |
|
|
|
|
BEF-400SX-60SM▼ ▲ | 400W | 90V~264V | 2.8V~5V | 235×60×30mm | |
|
|
|
|
BEP-400SX-60SM▼ ▲ | 400W | 176V~264V | 2.8V~5V | 235×60×30mm | |
|
|
|
|
BEF-500SX-60M▼ ▲ | 500W | 90V~264V | 2.8V~5V | 208×60×26mm | |
|
|
|
|
BEP-500SX-60M▼ ▲ | 500W | 176V~264V | 2.8V~5V | 208×60×26mm | |
|
|
